Locomotive body lifting device

The mobile vehicle lifting machine is used for vehicle shunting in the maintenance depot and the lifting operations in the engineering garage. With four units in a group, it can simultaneously lift one locomotive/engine vehicle and ensure the synchronized operation of lifting and lowering, as well as the provision of a mobile passage. This lifting machine features smooth lifting, precise synchronization, convenient movement, and high safety and reliability. It is designed to facilitate the assembly, maintenance, and replacement operations of the vehicle body, bogies, and bottom braking system components.

The lifting capacity of a single mobile vehicle lifting machine is ≥ 25t/30t/40t. It can be customized according to your requirements.

The lifting capacity of a single set of mobile vehicle lifting units is ≥ 100t/120t/160 units.

Lifting/ lowering speed                           Approximately 190mm/min

The height of the bracket at its lowest position (above the track surface) ≤ 700mm

Housing travel range                           ≥ 1500mm

The electrical protection level shall be no less than IP55; the insulation grade of the motor shall be no less than class F.
