Traction bar disassembly and assembly vehicle

one Equipment Usage:

This equipment is suitable for the maintenance operations of removing and assembling the traction rods from the vehicle body of harmonious type locomotives. This tool is specially designed and configured for the traction rods, and is used in the underground passage. The hydraulic pump is used to separate the traction rod from the traction support, and the lifting trolley is used to move the disassembled traction rod along the underground passage for removal and insertion.

II. Technical Specifications

Power Supply: AC 220V 50HZ

Equipment power: 1.5kW

Lifting trolley load capacity: 3 tons

Maximum lifting stroke: ≥ 700mm

Maximum lifting height: ≥ 160

Horizontal adjustment stroke: 100mm

Vertical adjustment stroke: 100mm

Battery voltage: DC24V

Oil injection equipment pressure: ≥ 30 MPa

Overall dimensions (mm): Approximately 2200 × 800 × 900 (The height can be adjusted appropriately according to the depth of the trench)

Included charging cable length (m): 10m

Traveling wheel (polyurethane) diameter (mm): 20

Operation method: Vehicle-mounted line control + wireless remote control
