Driver control unit test bench

This is applicable for testing the logical relationship of contact closure of the driver controller for HXD3, 3C, and 3CA models. It also tests the performance of contact resistance, etc. The normal resistance of the adjustable potentiometer, the smoothness of adjustment, and the linearity are also tested.

Technical Specifications

Working power supply:  220V ± 10% 50Hz 2kW;

Output power: 24 ± 0.1 VDC;

Measurement range:  0 - 50V  (accuracy: 0.1 class)

Logical measurement points: 46 routes;

Resistance measurement range: 0.005 to 100 Ω, ±2 mΩ;
