Electrically-powered process for replacing bogie assembly

one Equipment Usage

This equipment is suitable for use after the bogie is separated during vehicle maintenance. It can replace the bogie to provide positioning and support for the vehicle body, and can also move along the track at a low speed along with the vehicle.

II. Technical Specifications

(Dynamic steering frame)

Track gauge (mm): 1435

Inner distance of wheelset (mm): 1353 ± 1

Work running speed (m/min): 0 - 15 (adjustable)

Wheel diameter (mm): 810

Power supply method: 12V battery pack

Dust and water resistance rating: IP65

Battery pack capacity (Ah): ≥ 180

Control method of the drive device: Wireless control + On-board box control

Single unit carrying capacity (t): 150

Platform height: The distance from the centerline of the coupler to the rail surface must be no more than 880mm.

(2) Non-powered bogie

Track gauge (mm): 1435

Inner distance of wheelset (mm): 1353 ± 1

Dust and water resistance rating: IP65

Single unit carrying capacity (t): 50

Platform height: Satisfies the distance between the center line of the coupler and the rail surface ranging from 840mm to 880mm.

(3) Operating Environment

Altitude (m): ≤ 180

Working environment temperature (°C): -10 to 5

Relative humidity at work (percentage): ≤ 95

Working hours: Continuous operation at full load ≤ 3 hours

Power supply conditions: AC 220V (±10%) 50Hz / AC 380V (±10%) 50Hz
