Turning frame flipping equipment

Equipment Usage

This equipment is used for the flipping operation of the vehicle's steering frame or for other frame flipping operations in the relevant work areas.

Main technical parameters

Lifting motor power: 2.2KW

Reversing motor power: 1.5KW

Maximum load capacity: 5 tons

Lifting speed: 1000mm/min

Lifting range: 650 - 1900mm (vertical distance from the rotation center of the frame to the ground)

Reversal speed: 1 rpm

Reversal angle                360º (any position within the lifting range)
